Automatic Rigid Box Machine
It adopts high speed automatic paper feeding system, which is controlled pneumatically, and its structures simple and reasonable. It adopts PLC control, featuring in simple operation. The troubles are displayed directly on the HMl, which helps the operator easily remove them.
- Product Introduction
Machine Features
1. It adopts high speed automatic paper feeding system, which is controlled pneumatically, and its structures simple and reasonable.
2. It adopts PLC control, featuring in simple operation. The troubles are displayed directly on the HMl, which helps the operator easily remove them.
3. New designed copper scraper cooperates with the rubber more compactly, effectively avoiding paper winding. And the copper scraper is more durable.
4. Paper feeding and positioning system adopt imported high precise photoelectric control device to make the paper and cardboard location more accurate.
The Machine Main Parameters
|
Model |
JX-F450A-D |
|
Length of paper |
190-800mm |
|
Width of paper Thickness of paper |
130-460mm 80~200g/m² |
|
Thickness of cardboard |
1-5mm |
|
Min width of spine |
10mm |
|
Box Size (W*L*H) |
400*450*120mm, 90*60*15mm |
|
Position precision |
±0.2mm |
|
Production speed |
0-30 cases/min, 0-20 boxes/min |
|
Power |
10kw |
|
Weight |
4000kgs |
|
Dimension (L*W*H) |
8300×2200×2300mm |
